Description

 Specifications

Dimensions  :  420 x 420 x 230 mm (16.54 x 16.54 x 9.06″)

Weight  :  2.22 kg (4.89 lbs)

Power Supply   :  24V, 0.5A Gigabit PoE Adapter (Included)

Max. Power Consumption   :  8.5W

Power Method  :  Passive PoE (Pairs 4, 5+; 7, 8 Return)

Supported Voltage Range  :  20 to 26VDC

Gain   :  25 dBi

Networking Interface  : (1) 10/100/1000 Ethernet Port

Processor Specs  :  MIPS 74Kc

Memory  :  64 MB

LEDs  :  Power, Ethernet, (4) Signal Strength

Channel Sizes  :

PtP Mode     10/20/30/40/50/60/80 MHz

PtMP Mode     10/20/30/40 MHz

Enclosure Characteristics   :

Antenna Feed        Outdoor UV Stabilized Plastic

Dish Reflector         Powder-Coated SPCC

Mounting   :  Pole-Mounting Kit (Included)

Wind Loading  :   380 N @ 200 km/h (85.4 lbf @ 125 mph)

Wind Survivability    :  200 km/h (125 mph)

ESD/EMP Protection    :   Air: ± 24 kV, Contact: ± 24 kV

Operating Temperature   :   -40 to 70° C (-40 to 158° F)

RoHS Compliance   :  Yes
